Xiaomi Redmi Router AX6 WiFi6 6-Core 512M Memory Mesh Home IoT 6 Signal Amplifier 2.4G 5GHz Both 2 Dual-Band OFDMA NEW 2020 Wifi

New Xiaomi Redmi Router AX6 Wifi 6 Mesh Gigabit 2.4G/5.0GHz Dual-Band Wireless Router Wifi Repeater 6 High Gain Antennas WIFI 6

Product color: white
Processor: lPQ8071A4 core A531.4GHz CPU
Network acceleration engine: dual-core 1.7GHz NPU
Memory: 512MB
2.4G Wi-Fi: 2×2 (supports up to IEEE 802.11ax protocol, the theoretical maximum rate can reach 574Mbps)
5G Wi-Fi: 4×4 (supports up to IEEE 802.11ax protocol, the theoretical maximum rate can reach 2402Mbps)
Product antenna: 6 external high gain antennas
Product heat dissipation: natural heat dissipation
Machine interface:
1 10/100/100OM adaptive WAN port (Auto MDI/MDIX)
3 10/100/1000M adaptive LAN ports (Auto MDI/MDI×)
LED indicator: 2 (System indicator × 1, Internet indicator × 1)
System reset button: 1
Power input interface: 1
Protocol standard: IEEE 802.11a/b/g/n/ac/ax, IEEE 802.3/3u/3ab
Certification standards: GB/T9254-2008; GB4943.1-2011
Wireless parameters:
Dual frequency: 2.4GHz and 5GHz
Wireless channel:
2.4GHzChannel: 1,2,3,4,5,6,7,8,9,10,11,12,13
5GHz Channel: 36,40,44,48,52,56,60,64,149,153,157,161,165
Modulation
11b: DsSS: DBPSK (1Mbps), DQPSK (2Mbps), CCK (5.5/11Mbps)
11a/g: OFDM: BPSK (6/9Mbps), QPSK (12/18Mbps),
16QAM (24/36Mbps), 64QAM (48/54Mbps)
11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM.
Rate set: MCSO~MCS15
11ax: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM.
Rate set: MCSO~MCS11 (support 4 streams)
11ac: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM
Rate set: MCSO~MCS9 (support 4 streams)

operating system
Software parameters: MiWiFi ROM, a smart router operating system deeply customized based on OpenWRT
Wireless security: WPA-PSK/WPA2-PSK/WPA3-SAE encryption,
Wireless access control (black and white list), SSID hidden, intelligent anti-scratch network
Management application: support Web, Android, iOS

working environment
Working environment temperature: ~ 40 ℃
Working humidity: 10%~90%RH (non-condensing)
Storage temperature: -40～7o ℃
Storage humidity: 5%~90%RH (non-condensing)

Packing List:
Host × 1
Power cord×1
Chinese manual x1
